2 CH. Amplified Audio System
Brand Name
MISCO
Part #
TK-101
Built to Order
$119.98
The TK-101 system is a great choice for kiosks and digital signage, as well as entry-level gaming applications. Don't risk less than ideal sound via a la carte product choice, MISCO has done the work for you by pairing the right amplifier with the right speakers. While low in cost, the 101 provides plenty of high-intelligibility sound output thanks to the perfect match of the amplifier to the speakers.
Speakers
- 2 x 3.5 inches (50 x 90mm) wide range
- 8-Ohm, 10 Watt, 84dB sensitivity
- Shielded magnet prevents interference with electronic circuits and video displays
- Acrylic-treated cone surround for long life
- Speakers are not self-enclosed – will require mounting in cabinet with grilles
Amplifier
- Power output: 12.5W x 2
- PCB style
- Volume control
- Cool running and reliable Class D operation
- Wide 9-24VDC voltage input range
- Available MISCO power supplies: 36174 or PS15-VDC (sold separately)
This kit includes:
- Satellite Speaker - 84157 (x2)
- Amplifier - 93101
- Wire Harness - 36173
Download Product Specifications (PDF) »
| Brand Name | MISCO |
|---|---|
| Speaker System Type | Full Range |
| Enclosed Woofer Style | None |
| Subwoofer Type | None |
| RoHS Compliant | Yes |
| Digital Signal Processing | No |
| Audio Signal Input | Analog |
| Audio System Description | 2.1 Channel Full Range Satellite Speaker System |
| Audio System - Number of Channels | 2.1 (Stereo Sub) |
| System Frequency Response | 170 - 20kHz |
| Key System Features | Two wide range race-track shaped satellite speakers, one two channel class D amplifier, one 48" wire harness |
| Satellite Impedance | 8 |
| Satellite Frequency Range | 170 - 20kHz |
| Satellite - Key Features | 8-Ohm, 10 Watt, 84dB sensitivity , shielded magnet, acrylic-treated cone |
| Enclosure Style | Ported |
| Amplifier Style | Printed Circuit Board |
| Amplifier Description | Two Channel Class D Amplifier with LC Filtered Output |
| Amplifier Class Type | Class-D |
| PCB Size (HxWxL) (mm) | 0.6" x 2.25" x 2.5" (15.3 mm x 57.1 mm x 63.7 mm) |
| Amplifier Channel Count | 2.1 Stereo with Subwoofer |
| Audio Input | Analog Input |
| Digital Input S/PDIF | No |
| 8 Ω both HF channels driven (Watts RMS) | 13.5 W |
| Total Low Frequency (Sub-woofer) Output Power per channel into 4 Ω. (Watts) | 9.5W |
| Recommended Voltage (VDC) | 15 |
| Recommended Current (A) | 2 |
| Recommended Power (W) | 30 |
| Connectors / Termination - Speaker Input | 3.5 mm Audio Jack, 3 Position Mini Fit JR |
| Connectors / Termination - Speaker Output | L/R: 4 Position Mini Fit JR |
| Barrel Plug Connector Size (mm) | 2 |
| Wire Harness Description | L/R: 2 Position Mini Fit JR, To Amp: 4 Position Mini Fit JR |
| Wire Harness Length | 48" |
