2 Inch (50 mm) Wide Range Speaker, Shielded Magnet
A football-shaped wide-range speaker with a shielded magnet—ideal for voice communications and signal/alarm systems like medical devices, gaming cabinets, and measurement hardware requiring a high-reliability audio solution. This 8 ohm, 2" driver includes a 0.8 Oz ferrite magnet, a paper composite cone, and a treated cloth surround.
- Wide range speaker
- 2 inch (50 mm) steel basket diameter
- 3 watts, 8 ohm, 83 dB SPL
- 0.8 Oz shielded ferrite magnet
- Paper cone, treated cloth surround
Oaktron by MISCO is a premium line of high-performance, ready-to-ship transducers and drivers for various applications, including high fidelity, arcade and casino games, automotive, aerospace, and many more. From elegantly simple to highly specialized designs for unique and demanding applications, an Oaktron loudspeaker perfectly suits your needs.
MISCO engineers use the world's most sophisticated loudspeaker measurement systems, including the Klippel Analyzer, to maximize and validate the speaker's design and the Klippel QC module to ensure perfect unit-to-unit consistency and reliability.
Download Product Specifications (PDF) »
| Brand Name | Oaktron by MISCO |
|---|---|
| Model # | 50-WB08-01 |
| Size, Nominal (inch & mm) | 2" (50 mm) |
| Shape of Speaker | Other |
| Speaker Type | Wide Range |
| Application | Arcade Gaming, Casino Gaming, Medical, Voice Communications |
| Environment | Indoor |
| RoHS Compliant | Yes |
| Nominal Impedance (Z) (Ω) | 8 |
| Rated Power IEC268-5 (W) | 3 Watts |
| Rated Impedance (Ω) | 8 |
| Continuous Power (W) | 3 |
| Program Power (W) | 5 |
| Frequency Range (Hz) | 90 - 20,000 |
| Sensitivity (dB SPL) ¹ | 83 |
| Resonant Frequency (Fs) (Hz) +/- 15% | 187 |
| DC Resistance (Re) (Ω) | 7.6 |
| Voice Coil Inductance (Le) (mH) | 0.15 |
| Mechanical Q Factor (Qms) | 3.93 |
| Electrical Q Factor (Qes) | 2.19 |
| Total Q Factor (Qts) | 1.41 |
| Mechanical Resistance (Rms) (kg/s) | 0.32 |
| Compliance Equivalent Volume (Vas) (L) | 0.13 |
| Suspension Compliance (Cms) (mm/N) | 0.59 |
| Surface Area of Diaphragm (Sd) (cm²) | 12.57 |
| Moving Mass (Mms) (gm) | 0.93 |
| Motor Force Factor (BL) (T•M) | 2.08 |
| Efficiency (η₀) (%) | 0.06 |
| Efficiency Bandwidth Product (EBP) (Fs/Qes) | 85.23 |
| Basket Type | Stamped Steel |
| Terminal Size (mm) | 2.8 X 0.5 |
| Voice Coil Wire Material | Copper clad steel |
| Voice Coil Winding | 2 Layer, Round Wire |
| Magnet Material | Ferrite |
| Magnet Weight (g) | 21.55 |
| Cone Body Material | Paper |
| Cone Surround Material | Treated cloth |
| Dust Cap Material | Paper |
| Spider Material | Cotton |
| Net Weight (kg) | 0.11 |
| Technical Notes | ¹Sensitivity is measured with 2.83 volt input, measured on-axis at 1 meter distance |
