5 Inch x 7 Inch (127 mm x 179 mm) 4 Ohm, Wide Range Speaker
The 93090 wide-range speaker serves as a durable replacement driver for car audio systems. This Oaktron speaker delivers crisp upper frequencies thanks to its secondary high-frequency paper cone and a large ferrite magnet.
- Wide range speaker
- 5 in. x 7 in. (127 mm x 179 mm) basket diameter
- 15 watts, 4 ohms, 95 dB SPL
- 1 in. copper voice coil, aluminum former
- Ferrite magnet, stamped-steel basket
- Paper cone, treated cloth surround
Oaktron by MISCO is a premium line of high-performance, ready-to-ship transducers and drivers for a wide variety of applications, including high fidelity, arcade and casino games, automotive, aerospace, and many more. From elegantly simple to highly specialized designs for unique and demanding applications, there is an Oaktron loudspeaker perfectly suited for your needs.
MISCO engineers use the world's most sophisticated loudspeaker measurement systems, including the Klippel Analyzer, to maximize and validate the speaker's design, as well as the Klippel QC module to ensure perfect unit-to-unit consistency and reliability.
Download Product Specifications (PDF) »
| Brand Name | Oaktron by MISCO |
|---|---|
| Model # | 127X179-FR04-01 |
| Size, Nominal (inch & mm) | 5" Oval (127 mm) |
| Shape of Speaker | Oval |
| Speaker Type | Wide Range |
| Application | Home Audio |
| Environment | Outdoor / Indoor |
| RoHS Compliant | Yes |
| Nominal Impedance (Z) (Ω) | 4 |
| Rated Power IEC268-5 (W) | 15 Watts |
| Rated Impedance (Ω) | 4 |
| Continuous Power (W) | 15 |
| Program Power (W) | 30 |
| Frequency Range (Hz) | 75 - 12,000 |
| Sensitivity (dB SPL) ¹ | 95 |
| Resonant Frequency (Fs) (Hz) +/- 15% | 121 |
| DC Resistance (Re) (Ω) | 3.4 |
| Voice Coil Inductance (Le) (mH) | 0.14 |
| Mechanical Q Factor (Qms) | 3.71 |
| Electrical Q Factor (Qes) | 1.04 |
| Total Q Factor (Qts) | 0.81 |
| Mechanical Resistance (Rms) (kg/s) | 1.30 |
| Compliance Equivalent Volume (Vas) (L) | 5.96 |
| Suspension Compliance (Cms) (mm/N) | 0.27 |
| Surface Area of Diaphragm (Sd) (cm²) | 124.1 |
| Moving Mass (Mms) (gm) | 6.4 |
| Magnetic Gap Height (mm) | 4.5 |
| Coil Winding Height (mm) | 6 |
| Maximum Linear Excursion (Xmax) (mm) | 0.8 |
| Motor Force Factor (BL) (T•M) | 4.0 |
| Efficiency (η₀) (%) | 0.97 |
| Efficiency Bandwidth Product (EBP) (Fs/Qes) | 116.5 |
| Basket Type | Stamped steel |
| Terminal Size (mm) | 14.3 x 3.2 |
| Voice Coil Diameter (mm) | 25.8 |
| Voice Coil Wire Material | Copper |
| Voice Coil Former Material | Aluminum |
| Voice Coil Winding | 2 layer, round wire |
| Magnet Material | Ferrite |
| Magnet Weight (g) | 283.5 |
| Cone Body Material | Paper |
| Cone Surround Material | Treated cloth |
| Dust Cap Material | Paper |
| Net Weight (kg) | 0.85 |
| Technical Notes | ¹ Sensitivity is measured with 2.83 volt input, measured on-axis at 1 meter distance |
