3 Inch (77 mm) 4 Ohm, 15 Watt, Wide Range Speaker
Brand Name
MISCO OEM
Part #
EEN3W-4A
Built to Order
$29.99
This very compact, wide-range speaker is well-suited for both voice and music. With an acoustically dampened treatment on the engineered paper cone, it is a broad, flat frequency response. Its motor is made of a unique dual neodymium magnet design, which "turbo-charges" the speaker to provide high sensitivity and high power handling.
- 30 Watts of program power handling
- High output sensitivity for increased per-watt output
- High-compliant, natural rubber surround
- Black powder-coated steel basket
- Maximum Energy (ME) dual neodymium magnet
Note: This speaker has a tall surround for high excursions; therefore, grille placement cannot be flushed to the front of the cone.
Download Product Specifications (PDF) »
| Brand Name | MISCO OEM |
|---|---|
| Speaker Type | Wide Range |
| Shape of Speaker | Square |
| Size, Nominal (inch & mm) | 3" (77 mm) |
| Environment | Indoor |
| Application | Arcade Gaming, Casino Gaming, Drive-Thru / Kiosk, Voice Communications |
| RoHS Compliant | Yes |
| Rated Impedance (Ω) | 4 |
| Rated Power IEC268-5 (W) | 15 Watts |
| Program Power (W) | 30 |
| Sensitivity (dB SPL) ¹ | 87 |
| Frequency Range (Hz) | 110 - 14,000 |
| DC Resistance (Re) (Ω) | 3.1 |
| Resonant Frequency (Fs) (Hz) +/- 15% | 111 |
| Nominal Impedance (Z) (Ω) | 4 |
| Voice Coil Inductance (Le) (mH) | 0 |
| Mechanical Q Factor (Qms) | 1.3 |
| Electrical Q Factor (Qes) | 0.5 |
| Total Q Factor (Qts) | 0.36 |
| Basket Type | Stamped steel powder coated |
| Terminal Size (mm) | 2.8 x 0.5 |
| Voice Coil Diameter (mm) | 20.3 |
| Voice Coil Wire Material | Copper |
| Voice Coil Former Material | Aluminum |
| Magnet Material | Dual neodymium |
| Magnet Weight (g) | 23 |
| Cone Body Material | Treated paper |
| Cone Surround Material | Natural rubber |
| Spider Material | Cotton |
| Dust Cap Material | Treated paper |
| Net Weight (kg) | 0.11 |
| Technical Notes | ¹ Sensitivity is measured with 2.83 volt input, measured on-axis at 1 meter distance |
